LPWA Modules: Low Power. Small Footprint. Deep Coverage.

  NEW   – HL781x LPWA modules now support Non-Terrestrial Networks (NTN) for uninterrupted global connectivity.

LPWA Modules

HL78 module

Release 14 Cat-M1 / Cat-NB2​

Module
Region (Carrier)
Bands
Fallback
Details
HL7810
Global
B1, B2, B3, B4, B5, B8, B9, B10, B12, B13, B17, B18, B19, B20, B23, B25, B26, B27, B28, B66, B85, B255, B256
NTN
View Module
HL7812
Global
B1, B2, B3, B4, B5, B8, B9, B10, B12, B13, B17, B18, B19, B20, B23, B25, B26, B27, B28, B66, B85, B255, B256
2G, NTN
View Module
HL7845
Europe
LTE: B1, B3, B5, B8, B20, B31, B72, B87, B88
View Module

Release 13 Cat-M1 / Cat-NB1

Module
Region (Carrier)
Bands
Fallback
Details
HL7800
Global (AT&T, Verizon, Sprint, SouthernLINC, Rogers, Telus, NTT Docomo, KDDI, Vodafone, Deutsche Telekom, Telstra, Spark, Semtech)
LTE: B1, B2, B3, B4, B5, B8, B9, B10, B12, B13, B17, B18, B19, B20, B25, B26, B27, B28, B66
View Module
HL7802
Global (AT&T, Orange, Verizon, Vodafone, Semtech)
LTE: B1, B2, B3, B4, B5, B8, B9, B10, B12, B13, B17, B18, B19, B20, B25, B26, B27, B28, B66
2G
View Module

Semtech LPWA Module Advantages

Limited-Battery-Life-of-Remote-Devices-in-the-Field icon

Ultra Low Power

Power consumption by our LPWA modules is as low as 1.8uA for PSM floor current, and 30uA for eDRX floor current.

Security icon

Secure Element

Our LPWA products store security keys in a hardware-based secure element for an added layer of security.

Worldwide icon

Worldwide Bands

Our NB-IoT and LTE-M modules offer a wide selection of bands (up to 20) for scalability across the world.

Smart City icon

High Transmit Power

Low-frequency and high transmit power (23dBm to 26dBm) ensure resilient connection even in challenging locations such as underground and remote areas.

Frequently Asked Questions

Low Power Wide Area. It refers to low data rate, long range networking technologies that enable the transmission of sensor data from IoT devices with little board space and may be battery powered. The most prominent LPWA technologies are LTE Cat-M, NB -IoT (both are cellular), and LoRaWan. LPWA technologies are opening up new low-bandwidth IoT applications, including many industrial, smart-city, and agricultural applications.
A Cellular LPWA module is a module that supports LTE Cat-M and/or NB -IoT technologies. The low power consumption of the LPWA module makes this technology particularly suitable for battery-powered IoT devices where the battery is expected to remain in service for 10 years or more without human intervention. LPWA modules are less expensive and provide good coverage in underground and indoor environments. Thanks to these features, LPWA modules are used in smart electricity, water and gas meters, which are often installed underground.
Cellular LPWA technology is considered 5G if the device complies with 3GPP Release 15 or higher. This low-cost, low-power, wide-area, high-capacity technology provides low-speed (145Kbps – 1Mbps) connectivity for sensor data transmission. It is suitable for Massive IoT (or mMTC) use cases such as asset tracking and smart metering.

Connect with an IoT Expert

Have an expert help you choose an IoT module that best fits your project.
